3-PC FULL PORT SANITARY BALL VALVE

IT-S31
Stainless Steel

AISI-316 (EN10213 1.4408) (ASTM-A351-CF8M) SIZE: 1/2”~3”

  • Full cavity filler seats
  • Blow-out proof stem
  • Investment casting body and cap
  • 1000 PSI (63 BAR): 1/2”~2”
  • 800 PSI (40 BAR): 2-1/2”~ 3”
  • Mounting holes ISO 5211
  • Clamp end: 3A standard
  • Butt Weld end
  • Inside port ra≦0.4µm
  • Outside polished ra≦0.3µm
Alternative Option
  • Butt Weld end cap: AISI-316L
  • Body material: AISI-316L, AISI-304
  • RJT male end
  • Drain hole design
