2-PC FULL PORT BALL VALVE, 150LBS/ 300LBS, DIRECT MOUNTING PAD

IT-215
2-PC FULL PORT BALL VALVE, 150LBS/ 300LBS, DIRECT MOUNTING PAD
2-PC FULL PORT BALL VALVE, 150LBS/ 300LBS, DIRECT MOUNTING PAD
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: 1/2”~6”
  • Rating: ANSI B 16.5 class 150 or class 300
  • Flanged end
  • Face to face: ANSI B16.10
  • Full port
  • Blow-out proof stem
  • Direct Mounting pad ISO 5211 for actuator assembling
  • Anti-static device, Fire safe design
  • Solid ball
  • Investment casting body & flange
  • Lever operation
Alternative option:
  • Locking handle (Different mould)
