2-PC FULL PORT BALL VALVE, PN16/ 40, DIRECT MOUNTING PAD

IT-214
2-PC FULL PORT BALL VALVE, PN16/ 40, DIRECT MOUNTING PAD
2-PC FULL PORT BALL VALVE, PN16/ 40, DIRECT MOUNTING PAD
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: DN15-DN150
  • Rating: EN1092-1 PN16/40
  • Flanged end
  • Face to face: DIN3202 F4 / F5
  • Full port
  • Blow-out proof stem
  • Direct Mounting pad ISO 5211 for actuator assembling
  • ISO 15848-1 approved
  • Anti-static device, Fire safe design
  • Solid ball
  • Investment casting body & flange
  • Lever operation
Alternative option:
  • Fire safe API 407 approved
  • Locking handle (Different mould)
  • Hollow ball design
