2-PC FULL PORT BALL VALVE, 150LBS

IT-211
2-PC FULL PORT BALL VALVE, 150LBS
2-PC FULL PORT BALL VALVE, 150LBS
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size:1/2”~12”
  • Rating: ANSI B16.5 Class 150
  • Flanged end
  • Full port
  • Blow-out proof stem
  • Mounting pad ISO 5211
  • Anti-static device, Fire safe design
  • Investment casting body & flange
  • Lever handle: 1/2”~4”
  • Round bar handle: 5”~12”
Alternative option:
  • Solid ball/ Hollow ball/ Welded ball
  • Locking device
